| Display |
|
Panel Size:Wide Screen 27.0"(68.6cm) 16:9
|
| |
|
Color Saturation : 72%(NTSC)
|
| |
|
Panel Type : IPS
|
| |
|
True Resolution : 1920x1080
|
| |
|
Display Viewing Area(HxV) :597.6 x 336.15 mm
|
| |
|
Display Surface : Non-glare
|
| |
|
Pixel Pitch :0.311 mm
|
| |
|
Brightness(Max) : 400 cd/㎡
|
| |
|
ASUS Smart Contrast Ratio (ASCR) : 100000000:1
|
| |
|
Viewing Angle (CR≧10) : 178°(H)/178°(V)
|
| |
|
Response Time : 1ms MPRT
|
| |
|
Display Colors : 16.7M
|
| |
|
Flicker free
|
| |
|
Refresh Rate(max) : 144Hz
|
| |
|
|
| Video Feature |
|
Trace Free Technology : Yes
|
| |
|
GamePlus(modes) : Yes (Crosshair/Timer/FPS Counter/Display Alignment)
|
| |
|
Low Blue Light : Yes
|
| |
|
HDCP support : Yes
|
| |
|
VividPixel : Yes
|
| |
|
GameVisual : 7 Modes(Scenery/Racing/Cinema/RTS/RPG/FPS/sRGB Modes/MOBA Mode)
|
| |
|
FreeSync™ technology supported
|
| |
|
GameFast Input technology
|
| |
|
|
| Audio Features |
|
Stereo Speakers : 2W x 2 Stereo RMS
|
| |
|
|
| I/O Ports |
|
Signal Input : HDMI(v1.4), DisplayPort 1.2, Dual-link DVI-D
|
| |
|
Audio Output : 3.5mm Mini-Jack
|
| |
|
Earphone jack : 3.5mm Mini-Jack
|
| |
|
|
| Signal Frequency |
|
Digital Signal Frequenzy: DisplayPort：162 ~162 KHz (H) /48 ~144 Hz(V)
HDMI : 30 ~162 KHz (H) /48 ~144 Hz(V)
|
| |
|
|
| Power Consumption |
|
Power Consumption <40W*
|
| |
|
Power Saving Mode <0.5W
|
| |
|
Power Off Mode <0.5W
|
| |
|
|
| Mechanical Design |
|
Chassis Colors : Black
|
| |
|
Tilt : +33°~-5°
|
| |
|
Swivel : -90°~+90°
|
| |
|
Pivot : +90°~-90°
|
| |
|
Height Adjustment : 0~130 mm
|
| |
|
VESA Wall Mounting : 100x100mm
|
| |
|
|
| Security |
|
Kensington lock
|
| |
|
|
| Dimensions |
|
Phys. Dimension with Stand(WxHxD) : 619x (376~506)x211 mm
|
| |
|
Phys. Dimension without Stand (WxHxD) : 619x363x50 mm
|
| |
|
Box Dimension(WxHxD) : 700x458x190 mm
|
| |
|
|
| Weight |
|
Weight without stand : 3.2 kg
|
| |
|
Gross Weight (Esti.) : 8.2 kg
|
| |
|
|
| Accessories |
|
Dual-link DVI cable (Optional)
|
| |
|
Audio cable
|
| |
|
Power cord
|
| |
|
Power adapter
|
| |
|
DisplayPort cable (Optional)
|
| |
|
Quick start guide
|
| |
|
HDMI cable (Optional)
|
| |
|
|
| Compliance and Standards |
|
BSMI, CB, CCC, CE, CEL level 1, CU, ErP, FCC, J-MOSS, KCC, PSE, RoHS, UkrSEPRO, UL/cUL, VCCI, WEEE, WHQL (Windows 10, Windows 8.1, Windows 7), MEPS, RCM, TUV Flicker-free , eStandby, TUV Low Blue Light, ICES-3, PC recycle
|
